EMPI GTV-2 L5 CNC Ported Cylinder Heads 40 x 35.5 S/S Valves, Dual Hi-Rev Valve Springs for 94mm Bore, Complete w/ Performance Valve Job, Pair

Part Number: 98-1551-B

The EMPI GTV-2 Cylinder head casting out-classes all the competition! These new port designs include most of what DRD Racing Heads previously offered. Our programs cut the Intake Port, Exhaust Port and Combustion Chamber with CNC precision. You now have a smooth, ready to bolt on finished head. Beefed up Intake & Exhaust Ports allow massive porting without the need for welding. Special Aluminum Alloy for strength and durability, plus is repairable. Added material surrounding the combustion chamber for deep fly cutting exhaust air passages are clear for proper cooling. Complete GTV-2 Dual Port Heads, 94mm Bore, assembled with 40x35.5mm Stainless Steel Manley Valves, Dual Hi-Rev Valve Springs, Chromoly Retainers, Hardened Keepers, Rocker, Exhaust and Intake Studs. Custom Intake Gasket included. Complete with a 3-Angle Performance Valve Job.

12 mm 3/4” Spark Plug Holes

Chamber Volume: 64cc
Intake Port Volume: 72.5cc
Exhaust Port Volume: 80cc

Lash Caps P/N 00-4006-0 are required in all cylinder head applications that have Stainless Steel Valves.

WARNING: This product can expose you to chemicals including Lead which are known to the State of California to cause cancer and reproductive harm. For more information, go to www.P65Warnings.ca.gov. Wash hands following installation or before eating. All parts legal for use on pre-pollution controlled vehicles only.
